TrailPak - Stage 4 (15-22 Colorado/Canyon)

Regular price$3,499.99
/
Shipping calculated at checkout.

Reservoir Option
Spring Rate

Where it starts to get serious. The TrailPak Stage Series Stage 4 is designed for the Colorado Zr2 owner with serious off-road capability in mind.

    • Includes everything from the Stage 3 kit for a complete upgrade
    • Swapping out the 1-1/4 inch level kit for the Carbon Shock Technologies front & rear shock package!

    The TrailPak Stage 4 removes all the stops and takes your ZR2 to the next level.  The Carbon Shock Technologies replacement shocks feature:

    • 2.5" Body shocks that are 100% Rebuildable and Customizable.
    • Coilover front shocks offer adjustable ride heights and load capabilities with customizable spring rates and valving
    • Optional Dual Speed Adjustable Reservoirs for easy on vehicle fine tuning.

    If you're ready to unleash your vehicle's full off-road capabilities, the TrailPak Stage 4 is the upgrade you've been waiting for.

    Included from Stage 3:

    • Skid Plate Support Bracket & Rear Shock Relocation kit Protect vital undercarriage components with a Skid Plate Support Bracket and Rear Shock Relocation Kit
    • Tie Rod Wrench Easily replace tie rods on the trail with the included Tie Rod Wrench (Only fits ZR2 Tie Rods. ZR2 Inner Tie Rods are an easy bolt-on upgrade for any Colorado or Canyon and we recommend them for off-road use)
    • 1 Inch Front Diff. Drop Lower the front differential to keep your CV angles in check with the 1-inch front diff drop kit

    This discounted accessory bundle gives you everything you need to upgrade your truck's capability, protection, and performance. Elevate your adventures to the next stage.


    Carbon Shock Technologies Chevy Colorado ZR2 (2017-2022) 2.5″ Front Coilover Kit



    The Carbon Shock Technologies 2.5″ Front Coilover Kit is designed for seamless installation on your 2017-2022 Chevy Colorado ZR2.



    These coilovers are custom valved to meet your specific requirements upon request, and each coilover includes an internal top-out spring. This spring ensures a smooth slowdown of the shock at full extension, promoting longer component life and eliminating the clunking commonly heard in IFS vehicles.



    The billet OE mount top hats feature premium stainless steel hardware, guaranteeing long-lasting, corrosion-resistant performance.



    Reservoir Options:

    • No Reservoir
    • Standard 2.5" Non Adjustable Reservoir
    • 2.5" Dual Speed adjuatble Reservoir


    Kit Includes the following:

    • 2 Coilovers With Springs installed (Optional Springs Rates from 550-700.)
    • OE Mounting Factory fitting hats installed
    • Heavy Duty 1.25" Bar Pin
    • Billet OE Mounting Top Hat
    • Stainless Steel Hardware
    • Reservoir mounts with protected hose clamps if purchasing with a reservoirs option
    • Stickers


    Please contact us with questions and we can help guide your spring rate and valving needs.



    Key Features:

    • Precision Honed Steel Bodies
    • Optional Stainless Steel Bodies ( Contact Carbon or authorized Dealer for pricing and availability)
    • Durable Cerakote Finish
    • Billet Aluminum Reservoirs for efficient cooling
    • Internal Top Out Spring
    • Effortless adjustable preload, courtesy of dual-threaded shock bodies
    • PTFE Spherical Bearings
    • Robust Hardened Shock Shafts
    • High-quality American Made Dysogrin Seals.
    • Shock Length Extended: 23.22"
    • Shock Length Compressed: 17.87"
    • Shock Travel Standard: 5.35"

      Valving Options if custom valving is requested:

      Please Choose from the following so we can better valve your shocks to your specific truck and application.

      1. Do you run Sway bars?
      2. Driving style
      A. Daily Driver + Light Offroad - Occasional Dirt Roads but your primary life is on the road.

      B. Daily Driver + Heavy Offroad - Mild Rocks and woops are your home but not to fast because you still need to drive home in it but want to have fun!

      C. Daily Drive + Overlander - Mild wheeling but supportive for heavy equipment loads and control. Slower suspension cycling but able to put in work.

      D. Heavy Offroad - Not afraid to push the vehicle to it limits and take the big hits at higher speeds. Fine for on road driving but stiffer and not as plush.



    • Fits 2017-2022 Colorado ZR2 and ZR2 Bison with diesel or gas engines
    • Easy bolt-on installation
    • 8-10 hour install time
    • Made in USA
    • Installation Instructions
      • It is recommended that an alignment is done after installing this kit

    Wheel and Tire Specs (some trimming may be required)

    • Tires: 33x10.50R17 or equivalent
    • Wheel BS: Factory
